Lift Controllers

The industries quickest lift control packages for both planned or reactive maintenance requirements.

An overview of our range

The majority of lift controllers packages are built and tailored within our UK facility from a huge range of off-the-shelf components. This method of assembly results in an industry-leading order to dispatch turnaround time and makes our lift controllers the perfect solution for both planned and reactive modernisations.

With a range of package options available, we can provide a stock solution for a huge range of lifts, from small home lifts to triplex high rise projects.

  • VVVF Lift Controller
  • Hydraulic Lift Controller
  • Hydraulic LRV Lift Controller
  • Hydraulic i-Valve Lift Controller

For the more complex requirements, we provide completely bespoke lift controller packages.

VVVF Lift Controller

Lift Controllers with a industry leading turnaround time.

We hold a range of VVVF Lift Controllers in stock, within our Bradford warehouse, with VVVF Drives ranging from 5.5kW 18 Amp to 15kW 40 Amp. Based around the DMG Pitagora 4.0 pre-wired system, out of the box, our lift controllers are set up for up to 8 floors with 1 x 240 VAC Door Operator and 110 VDC brake/retiring cam.

Our technicians then tailor these units to match your specific site requirements.

Key Features and Benefits

Additional Features and Benefits

Our stock VVVF lift controllers are set up with the below features as standard. Lift Controllers outside of this specification are available from our bespoke range.

  • 3 Phase Supply
  • 2 to 8 Floors
  • SAPB or Down Collective
  • 24 Hour Battery Test
  • 4 Point Safety Chain
  • Photocell Input NO/NC
  • Floor Level Indication
  • Motor Thermistor Input
  • Auto Shaft Learn
  • Last 60 Faults
  • Advance Door Opening
  • Setup to suit a 110 VDC Brake and Retiring Ramp voltage
  • Set for a 110 VDC Retiring Ramp voltage
  • Full load bypass and lift overload control
  • Star Delta Starting
  • Simplex Control
  • Set for 1 x 240 VAC Car Door Operator
  • Timed Car Lights Off
  • On Position Fire Recall
  • Out of Service
  • Short Floor Capacity
  • Selective or Simultaneous Door Control
  • Over 50 Faults Detected
  • Visual I/O Status
  • Programmable return zones (Weeks/Days/Hours/Minutes)
  • Programming module with LCD screen with every panel
  • Programmable 4 digit code for car call acceptance



Technical downloads

Discuss your requirements

Hydraulic Lift Controller

Lift Controllers with a industry leading turnaround time.

We hold a range of Hydraulic Lift Controllers in stock within our Bradford warehouse suitable for pump units up to 28kW with a maximum of 40 Amp contactors/ Based around the DMG Pitagora 4.0 pre-wired system, out of the box, our lift controllers are setup for up to 8 floors with 1 x 240 VAC Door Operator, 4 x 110 VDC solenoids and 110 VDC retiring cam.

Our technicians then tailor these units to match your specific site requirements.

Key Features and Benefits

Addititional Features and Benefits

Our stock hydraulic lift controllers are set up with the below features as standard. Lift Controllers outside of this specification are available from our bespoke range.

  • 3 Phase Supply
  • 2 to 8 Floors
  • SAPB or Down Collective
  • 24 Hour Battery Test
  • 4 Point Safety Chain
  • Photocell Input NO/NC
  • Floor Level Indication
  • Motor Thermistor Input
  • Auto Shaft Learn
  • Last 60 Faults
  • Advance Door Opening
  • Setup to suit 4 x 110 VDC value solenoids
  • Set for a 110 VDC Retiring Ramp voltage
  • Full load bypass and lift overload control
  • Star Delta Starting
  • Simplex Control
  • Set for 1 x 240 VAC Car Door Operator
  • Timed Car Lights Off
  • On Position Fire Recall
  • Out of Service
  • Short Floor Capacity
  • Selective or Simultaneous Door Control
  • Over 50 Faults Detected
  • Visual I/O Status
  • Programmable return zones (Weeks/Days/Hours/Minutes)
  • Programming module with LCD screen with every panel
  • Programmable 4 digit code for car call acceptance



Technical downloads

Discuss your requirements

Hydraulic LRV Lift Controller

Lift Controllers with a industry leading turnaround time.

We hold a range of Hydraulic LRV Lift Controllers in stock within our Bradford warehouse suitable for the Bucher LRV Pump Unit up to 28kW with a maximum of 40 Amp contactors. Based around the DMG Pitagora 4.0 pre-wired system, out of the box, our lift controllers are set up for a 415V Bucher NTA-2 power supply unit, 240 AC Door Operator and 110 VDC retiring cam.

The Bucher NTA-2 power supply unit and DELCON electronic card are available as optional extras.

Key Features and Benefits

Additional Features and Benefits

Our stock hydraulic LRV lift controllers are set up with the below features as standard. Lift Controllers outside of this specification are available from our bespoke range.

  • 3 Phase Supply
  • 2 to 8 Floors
  • SAPB or Down Collective
  • 24 Hour Battery Test
  • 4 Point Safety Chain
  • Photocell Input NO/NC
  • Floor Level Indication
  • Motor Thermistor Input
  • Auto Shaft Learn
  • Last 60 Faults
  • Advance Door Opening
  • Setup to suit a 415V Bucher NTA-2 PSU (optional extra)
  • Set for a 110 VDC Retiring Ramp voltage
  • Full load bypass and lift overload control
  • Star Delta Starting
  • Simplex Control
  • Set for 1 x 240 VAC Car Door Operator
  • Timed Car Lights Off
  • On Position Fire Recall
  • Out of Service
  • Short Floor Capacity
  • Selective or Simultaneous Door Control
  • Over 50 Faults Detected
  • Visual I/O Status
  • Programmable return zones (Weeks/Days/Hours/Minutes)
  • Programming module with LCD screen with every panel
  • Programmable 4 digit code for car call acceptance



Technical downloads

Discuss your requirements

Hydraulic i-Valve Lift Controller

Lift Controllers with a industry leading turnaround time.

We hold a range of Hydraulic Lift Controllers in stock within our Bradford warehouse suitable for the Bucher i-Valve Pump Unit up to 28kW with a maximum of 40 Amp contactors. Based around the DMG Pitagora 4.0 pre-wired system, out of the box, our lift controllers are set up for a Bucher iCon and Parameter Card, 240 VAC Door Operator and 110 VDC retiring cam.

The Bucher iCon and Parameter Card are available as optional extras.

Key Features and Benefits

Additional Features and Benefits

Our stock hydraulic LRV lift controllers are set up with the below features as standard. Lift Controllers outside of this specification are available from our bespoke range.

  • 3 Phase Supply
  • 2 to 8 Floors
  • SAPB or Down Collective
  • 24 Hour Battery Test
  • 4 Point Safety Chain
  • Photocell Input NO/NC
  • Floor Level Indication
  • Motor Thermistor Input
  • Auto Shaft Learn
  • Last 60 Faults
  • Advance Door Opening
  • Setup to suit a Bucher iCon and Parameter Card (optional extra)
  • Set for a 110 VDC Retiring Ramp voltage
  • Full load bypass and lift overload control
  • Star Delta Starting
  • Simplex Control
  • Set for 1 x 240 VAC Car Door Operator
  • Timed Car Lights Off
  • On Position Fire Recall
  • Out of Service
  • Short Floor Capacity
  • Selective or Simultaneous Door Control
  • Over 50 Faults Detected
  • Visual I/O Status
  • Programmable return zones (Weeks/Days/Hours/Minutes)
  • Programming module with LCD screen with every panel
  • Programmable 4 digit code for car call acceptance



Technical downloads

Discuss your requirements

Support Services

For planned or reactive modernisation, we have a range of services which are there to support you throughout the modernisation process.

Product Specification
Our team are here to assist you with your product specification for our lift modernisation packages.
Modernisation Oversight
We will oversee all your modernisation equipment to ensure full compatability with the products we supply.
Technical Support
All our lift component packages are fully supported by our in-house technicians and supply partners.
Lift Consultant Support
We are on-hand to assist lift consultants gain a better understanding of the products we supply.

Elevate the discussion

For a more detailed conversation regarding your requirements, get in touch with a member of our Lift Components team today.
